The quickest and easiest way to connect the Remote to a WiFi network or mobile hotspot is by using the OBD WiFi Connect app. The app is available for both Android and iOS devices.
1. Download and install the app
Download and install the OBD WiFi Connect app on your smartphone or tablet.
2. Connect the Remote to the vehicle
- Connect the Remote to the vehicle's OBD port
- Make sure the ignition is switched on
3. Set up the WiFi connection
- Open the OBD WiFi Connect App
- Follow the instructions shown in the app
- Select a WiFi network or mobile hotspot
- Enter the password and confirm the connection
⚠️ Important
- Carefully check the password for typing errors
- No error message will be shown if the password is incorrect
- If the password is entered incorrectly, the Remote will not be able to connect
4. Verify the connection
When both LEDs next to the Ethernet port remain continuously lit, the Remote is successfully connected to the network.
Important Information
The LEDs on top of the Remote may temporarily turn blue and the device may start beeping. This means that a software update is being downloaded. The Remote automatically downloads available updates whenever it is connected to a network.
During an update:
- Keep the Remote connected to the vehicle.
- Do not disconnect the device or interrupt the connection.
- Wait until the LEDs turn green again.
Once the LEDs are green, the update is complete and the Remote is ready for use.
